Impact’s Policy is to meet Customer Requirements of
Quality, Price & Service by employing latest technology,
improving productivity through continuous improvement
& focusing on customer satisfaction.
standards followed
ASTM Std C-1048
JIS Std R 3206 1989
BIS Std 858
IS : 2553 Part II 1992
DIN Std 1249
The Impact test lab is setup to comply towards
mechanical, optical and environmental
requirements and the tests are conducted as
per the following:
ECE – R43
DOT – 856
ANSI – Z.26
IS:2553 P-1 & P-2
test conducted
IMPACT RESISTANCE TEST
PENETRATION RESISTANCE TEST
HEAD FORM IMPACT TEST
RESISTANCE TO SHOCK TEST
OPTICAL DISTORTION TEST
SECONDARY IMAGE TEST
HIGH TEMPERATURE TEST
LIGHT STABILITY TEST
STRESS PATTERN IN TOUGHENED GLASS
PVB MOISTURE TEST
SAMPLE CONDITIONING TESTS
HOT AIR OVEN (0º - 200º C)
DEEP FREEZER( -28º TO 0ºC)
tests lab photos
final inspection
The system for the final inspection of automotive glass is designed for the inline inspection of car
glass in the production line and consists of three independent modules that detect and objectively
evaluate all important production defects. Recognized defects are gathered centrally and are
evaluated and visualized in an integrated user interface. It is possible to define different zones and
quality levels for each screen. The system inspects the glass edges, the massive silk print area,
the fade out band and the pure glass area.
